Canon imagePROGRAF TM-200 A1 Printer | 610mm
Canon TM-200 Finance Options
Lease the Canon TM-200 from just £35+ vat per month based over 36 monthly payments
Canon imagePROGRAF TM-200 A1 24" Printer
Trade in your current printer and save ££s on the Canon TM-200
*** FREE 2 YEAR WARRANTY & 200m Of Plotter Paper
When You Order A Canon TM-200 Printer ***
Pro Print Canon TM-200 Printer Review
The Canon TM-200 24" printer is a great all-rounder poster printer and is well suited to any working enviroment! The Canon TM-200 is hugely popular and is currently our number one selling CAD/ poster printer, offering a pigment ink system the Canon TM-200 allows you to print A1 prints on a variety media including poster paper, banner, vinyl, canvas and a range of outdoor media for short term outdoor advertising.
 |  |
Canon TM-200
The Canon TM-200 printer is redefining what a Large-format printer is capable of. The TM-200 printer is not only ideal for printing technical documents, CAD drawings and GIS maps, but also posters, signage and displays with the use of Canons LUCIA TD water resistant pigment ink.
Built with Canon developed technologies the imagePROGRAF TM-200 has a 5-colour LUCIA TD pigment ink, PF-06 print head, L-COA PRO image processor, along with a clear, intuitive operation panel and is nearly 60% quieter than previous models Plus there is a host of creative workflow software included.
Newly developed for this series is Free Layout Plus, a print utility that allows users to tile nest and create custom layouts before printing. Direct Print & Share, Canons cloud portal software, has new added features as does Canons poster creation software, PosterArtist Lite making this printer an easy choice for the architectural, engineering and construction industries as well as office environments.
Canon TM-200 Features
LUCIA TD Pigment Ink Set
The Canon TM-200 device features an all-new 5-colour TD pigment ink set. This ink was formulated to produce fine lines and sharp text on both inkjet and non-inkjet paper. Combine this pigment ink with water resistant media and you have a printed drawing that can withstand many outdoor conditions, especially outdoor job sites such as construction sites. Available in 130 ml or 300 ml ink tanks. 490 ml of ink ships standard with the TM-200.
Fast Printing
With faster printing of multipage files, the TM-200 printer can print up to 144 D sized prints per hour3!
Security Features
The TM-200 large-format printers come equipped with several security features designed to help prevent leaks of confidential information:
Secure Communication:
802.1x Authentication SNMPv3 SSL/TLS IPSec
Functionality Restrictions:
Panel Lock by Remote UI Remote UI Multilevel Hide IP From Panel Panel Access Control Job Storage and PIN Printing
Secure Storage:
Secure Disc Erase (Conforms to U.S. Department of Defense standard DoD5220.22-M)
The following functions can be disabled in administrator mode:
Direct USB Thumb Drive Printing Internet Connection FTP and Telnet communication protocols Job Log Look-up
Quiet Operation
The TM-200 is well suited for busy office environments as it is 60% quieter than previous imagePROGRAF printers and offers less distraction in the workplace.
Operation Panel
The TM-200 features a 3" colour touchscreen operation panel making it easy to view printer information as well as perform simple operations.
Small Footprint
A good fit for small offices, the compact TM-200 has the smallest footprint 24-inch large format aqueous inkjet printers.
Wi-Fi Compatible
Printing jobs quickly is critical on the work site and in the office. The Wi-Fi connectivity can transfer technical drawing files and help speed up your workflow- perfect for high-volume printing. No Wi-Fi router is needed, which can provide greater freedom during installation.
Print Head PF-06
The 6-channel PF-06 Print Head is engineered to work with the printer's high-speed carriage and high-frequency ink ejection to help facilitate fast printing. This printer boasts Canon's print-head technology that lays down ink with outstanding speed and accuracy. The PF-06 print head incorporates a nozzle orifice shape to help minimize mist spray, producing clean lines and text. The high-precision, high-density print head, with a total of 15,360 nozzles, lays down 5 picoliter-size ink droplets that help produce sharp detail and excellent image quality. The result is consistently accurate 2400 x 1200 dpi output (max.) with fine lines that are accurate to ±0.10% and as thin as 0.02mm.
Sub Ink Tank System
The Sub-Ink Tank System allows virtually all of the available ink in a tank to be used before having to replace it, helping to eliminate wasted ink. The empty tanks can also be replaced on-the-fly without stopping the printer. This is extremely useful during your long print jobs.
Canon TM-200 Technical Specification
| Printer Type | 5-Colour 24-inch Printer |
| Number of Nozzles | Total: 15,360 | MBK: 5,120 nozzles | C, M, Y, BK: 2,560 nozzles each |
| Nozzle Pitch | 1,200 dpi | Non-firing nozzle detection and compensation |
| OS Compatibility | Windows® 7, 8.1, 10 (32/64bit) | Windows® Server 2008 R2, 2012, 2012 R2, 2016 (64bit) | Macintosh OS X v10.10.5-v10.12x |
| Standard Interfaces | USB 2.0 High-Speed | 10/100/1000 Base-T/TX | Wireless LAN (IEEE 802.11 b/g/n) |
| Ink Droplet Size | 5 picoliter |
| Ink Capacity | 130 ml or 300ml per colour |
| Colour Set | Pigment: Matte Black, Black, Cyan, Magenta, Yellow |
| Buffer Ram | 2 GB (Physical) |
| Media Width | Cut Sheet - 8- 24 Roll Feed - 8 - 24 |
| Media Thickness | 0.07-0.8mm |
| Maximum Roll Print Length | Roll Feed - 59' (18 meters) |
| Maximum Media Roll Diameter | 5.9 (150mm) |
| Borderless Printing Width | 8, 10, 12, 14, 16 17, 20, 24 B4 (10.12/257 mm), A3 (11.69/297 mm), A3+ (12.95/329 mm), A2 (16.54/420 mm), B2 (20.28/515 mm), A1 (23.39/594 mm) |
| Paper Feed Method | Roll Feed: One Roll, Top-loading, Front | Output Cut Sheet: Top Loading, Front Output |
| Languages | SGRaster, HPGL/2, HP-RTL, JPEG |
| Noise Level Approx. | Operation: 44 dB (A) or less | Standby: 35 dB (A) or less | Acoustic Power: 6.0 Bels or less |
| Physical Dimensions | 42.0 x 38 x 34 |
| Weight | Approx. 112 lbs (roll holder included, no inks, no print heads) |
| Power Source | AC100-240V (50-60Hz) |
| Power Consumption | Maximum: 69W or less | Standby 3.6W or less | Power Off: 0.3W or less (Compliant with Executive Order) |
| Operating Environment | Temperature: 59°-86° F (15°-30° C) Relative Humidity: 10-80% (No Condensation) |
| User-Replaceable Items | Print Head (PF-06) | Maintenance Cartridge (MC-31) | Ink Tanks (PFI-120/PFI-320) | Cutter Blade (CT-08) |
| Software Included | TM Unified Printer Driver, Accounting Manager, Apple AirPrint, Canon Print Service, Device Management Console, Direct Print & Share, Free Layout Tool, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, PosterArtist Lite for Windows, Optimized Driver for AutoCAD, Canon PRINT Inkjet Selphy, Easy Photo Print Editor |
| Scanner Type | Contact Image Sensor (CIS) technology |
| Scan Accuracy | +/- 0.20% |
| Speed | 3 ips monochrome, 1 ips colour (Copy, Standard Mode) |
| Optical Resolutions | 600 dpi |
| Max Resolutions | 600 dpi |
| Max. Document Size | Width: 26 inch document width (24 inch image width) | Length: 109 inch | Thickness: 0.5mm |
| Standard Interface | (Scan to USB) USB 2.0 / (Scan to Network) Gigabit ethernet |
 |  |
